Digital Vibration Meter – Professional Diagnostic Tool

Digital Vibration Meter – Professional Diagnostic Tool

Key Features

✔ Dual Measurement Modes – Lo-RMS (10Hz–1kHz) for low vibrations & Hi-AVE (1kHz–15kHz) for high-frequency analysis
✔ Multi-Function Probes – Includes 3 measurement tips:

• Short tip – Standard vibration checks

• Long tip – Narrow/hard-to-reach areas

• Flat tip – Smooth surface measurements
  ✔ Precision Sensors – ±5% accuracy with external accelerometer (included)
  ✔ Magnetic Mount – Hands-free operation on metal surfaces
  ✔ Temperature Range – -10°C to +80°C (±2°C accuracy)

Technical Specs

• Display: Dual-row LCD (15mm/10mm digits) with backlight

• Frequency Range:

  • Low: 10Hz–1kHz (Lo-RMS)

  • High: 1kHz–15kHz (Hi-AVE)

• Power: 9V battery (included) | Auto shut-off after 1min

• Operating Conditions: 0°C–40°C | 30–90% RH

Professional Applications

• Predictive Maintenance – Detect bearing wear, misalignment, unbalance

• Industrial Machinery – Motors, pumps, gearboxes

• Aerospace – Engine & component vibration analysis

• Automotive – Drivetrain diagnostics

Package Includes

• Vibration meter

• External accelerometer + cable

• 3 probe tips (short/long/flat)

• Magnetic mount

• 9V battery

• Workshop test certificate

• Operation manual
