Mini Solid Carbide Boring bar(R050.35.16)TiALN Coated

$62.07
Solid carbide mini boring bar suitable for stainless steel, steels, and super alloys
Grade and Coating
TiALN
Mounting spigot diameter​ / DCONMS - d 1 Dia
4.00
Overall length / OAL - l 1 OAL
30.00
Corner radius / RE / R
0.10
Reduced body diameter length / LDRED
16
Minimum bore diameter / DMIN
3.5
Body diameter, reduced / BDRED
2.80
Cutting depth maximum / CDX
0.25
CW
0
Insert hand / IH
Right
PDPT
0
